OUR PRODUCTS

Thermally Broken Facade

FEATURES & BENEFITS

FEATURE

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vestibulum non neque at urna tempor luctus. Nullam placerat nulla id sem bibendum, et sagittis odio volutpat. Suspendisse nec dapibus elit.

FEATURE

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vestibulum non neque at urna tempor luctus. Nullam placerat nulla id sem bibendum, et sagittis odio volutpat. Suspendisse nec dapibus elit.

TECHNICAL SPECS

SKY CW45

Slim mullion-transom curtain wall for large spans

  • Resistance under wind load
    ±1375 Pa

    Security
    ±2062 Pa

    Air permeability
    AE

    Watertightness
    RE 1200

    Impact strength
    E5-I5

    Burglar resistance
    RC4

    Thermal transmittance
    Ucw ≥ 1,4 W/m²K

    Sound insulation
    ≤ 41 dB

SKY CW60

Mullion-transom curtain wall with a face width of 60 mm for large spans

  • Resistance under wind load
    ±1375 Pa / Security ±2062 Pa (facade) ±2000 Pa / Security ±3000 Pa (for 3° glass roof)

    Air permeability
    AE

    Watertightness
    RE 1200Impact strengthE5-I5

    Thermal transmittance
    Ucw ≥ 1,7 W/m²K

    Sound insulation
    ≤ 45 dB (vertical glazing)

SKY CW55

Mullion-transom curtain wall, also suited for 0° roof glazing solutions

  • Resistance under wind load
    +2000/-3200 Pa; Safety +3000/-4800 Pa

    Air permeability
    AE

    Watertightness
    RE 1800, RE 2400 (0° roof)

    Impact strength
    E5-I5

    Burglar resistance
    RC 3

    Thermal transmittance
    Ucw ≥ 0,59 W/m²K

    Sound insulation
    ≤ 47 dB

SKY CW60BR

Mullion-transom curtain wall for high safety requirements

  • Resistance under wind load
    ±1375 Pa, Security ±2062 Pa

    Air permeability
    AE

    Watertightness
    RE 1200

    Impact strength
    E5-I5

    Bullet resistance
    FB 6

    Burglar resistance
    RC4

SKY CW55SG

All-glass mullion-transom curtain wall (structural glazing)

  • Burglar resistance
    RC 2
